The MICROBLAZE Processor Board is a high-performance system featuring a Virtex 4 FPGA with an Embedded PowerPC 405 core. It supports up to 450 MHz operation and includes high-speed DDR2 memory and dual-channel Gigabit Ethernet connectivity.
Specification
- Virtex 4 FPGA with Embedded PowerPC 405 (PPC405) Core
- Up to 450 MHz operation
- Tri-mode Ethernet Media Access Controller
- A/D Converter Blocks (10-bit / 200 kilo samples per second)
- Select IO Technology (Wide selections of I/O standards from 1.5V to 3.3V)
- DDR2 SDRAM (256MByte)
- Program Storage Flash Memory (8MByte)
- Data Storage Flash Memory (8MByte)
- Vertex-4 FPGA PROM (4MByte)
Features
- Ethernet Port –10/100/1000Mbps Ethernet 2 Channels
- RS232/RS422 – 9 Channels
- Two SPI interfaces configured in Master-mode
- Synchro to Digital converter
- JTAG – Flash Programming and Debugging
