ARM LPC3250 Board

ARM LPC3250 Board

ARM LPC3250 Board

MS 1509


ENQUIRE NOW




Features

  • 32 Bit ARM LPC3250 Processor (256KB SRAM)
  • 133MHz External Bus Speed and 266 MHz internal CPU Speed
  • 32 Bit, 33MHz CPCI Bus, 6U Form Factor
  • External memory ( Flash – 2 MB, RAM - 512 KB, DPRAM – 128KB)
  • 10/100 MBPS Ethernet Interface
  • USB 2.0 Host/Device Interface
  • 2 RS232 Serial Ports, 4 RS422 Serial Ports
  • M Module Interface
  • 6U board compatible with CPCI & PXI backplanes
  • High Speed Logic Device
  • Hot Swap Feature
  • Front Panel and Rear IO Interface
  • External Bus through Rear IO
  • Reception of 3Kbytes within 2ms through Ethernet
  • Board Dimension is 160mm x 233.35mm
  • Power Requirements: +3.3V, +5V and +/-12V
  • Board Dimension is 160mm x 233.35mm
  • Board has Rear IO interface
  • Ethernet, JTAG, RS232, USB connectors at front side
  • BSPs and Driver software for Windows and Linux OS

Applications

  • Automatic Test Equipment
  • Data Acquisition System
  • Process Control Industries
  • Industrial Automation

C012 Card Features

  • Suitable for standard desktops
  • Four channel in single board
  • Up to 10 Mbits/sec operating speed
  • Low Cost solution
  • Standard INMOS link protocol
  • Communicates with transputers
  • Converts between serial link and parallel bus
  • Tristate bidirectional bus interface
  • Memory mapped registers
  • Interrupt capability
  • TTL compatibility

Applications

  • Connecting microprocessors to transputers
  • High speed links between microprocessors
  • Inter-family microprocessor interfacing
